The Intel Core i5-14600K is a 14-core, 20-thread processor with 6 Performance-cores and 8 Efficient-cores, a maximum boost clock of 5.3 GHz, a 125 W base power rating, and a turbo power draw that reaches approximately 181 W under sustained multi-core loads. The processor uses the LGA 1700 socket and pairs with 600-series and 700-series Intel chipsets, including H610, B660, B760, H770, Z690, and Z790.
A motherboard for the i5-14600K determines how consistently the CPU sustains its turbo power draw, which memory speeds the system reaches, how many high-speed storage devices the platform supports, and which networking and expansion features are available. A Z790 chipset motherboard unlocks full overclocking control and typically pairs a stronger VRM (voltage regulator module) with PCIe 5.0 connectivity and DDR5 memory support, which matches the i5-14600K’s power and bandwidth requirements more closely than lower-tier chipsets.
VRM phase count and power-stage amperage directly affect how well a motherboard delivers clean, stable voltage to the CPU during heavy multi-core workloads and overclocking. A board with a higher-rated VRM keeps voltage stable and temperatures lower when the i5-14600K draws its full 181 W turbo power, while a lighter VRM design still runs the CPU reliably at stock settings but leaves less headroom for sustained all-core boosting.
This article reviews six Z790 motherboards for the Intel Core i5-14600K across different price tiers, covering their specifications, how each board supports the processor’s power and connectivity needs, and how the boards compare against one another. A buying guide at the end summarizes the criteria for selecting the right board for a given build.
Best Motherboards for Intel i5-14600K CPU
MSI MAG Z790 Tomahawk MAX WiFi
CHECK PRICE
PROS
CONS
| Specification | MSI MAG Z790 Tomahawk MAX WiFi |
|---|---|
| Chipset | Intel Z790 |
| Form Factor | ATX |
| VRM | 16+1+2 phases, 90 A power stages |
| Memory | 4x DDR5, up to 256 GB, up to 7,800 MT/s (OC) |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4 mode), 1x PCIe 3.0 x1 |
| Storage | 4x M.2 (1x PCIe 5.0 x4), 8x SATA III |
| Networking | Wi-Fi 7, Bluetooth 5.4, 2.5G LAN (Intel I225-V) |
| Audio | Realtek ALC4080 |
| Rear USB | Thunderbolt 4 (USB-C, 40 Gb/s) |
| Approximate Price | $300 |
The MSI MAG Z790 Tomahawk MAX WiFi is an ATX motherboard built on the Intel Z790 chipset with a 16-phase Mirrored Power Arrangement VRM rated at 90 A per power stage, plus one GT-power phase and one auxiliary phase (16+1+2). Two 8-pin EPS power connectors feed the VRM, and MSI’s Core Boost technology and Duet Rail Power System route current for stable delivery under multi-core loads. This VRM configuration exceeds the i5-14600K’s 181 W turbo power draw with substantial headroom, so the board sustains all-core boost clocks without voltage throttling during extended workloads.
The board carries four DDR5 DIMM slots supporting up to 256 GB of memory at rated overclocked speeds up to 7,800 MT/s. Expansion includes a PCIe 5.0 x16 slot, a PCIe 4.0 x16 slot running at x4 electrical bandwidth, and a PCIe 3.0 x1 slot. Storage totals four M.2 slots, including a PCIe 5.0 x4 slot that shares bandwidth with the primary PCIe 5.0 x16 slot, alongside eight SATA III ports. Networking runs through a Wi-Fi 7 module with Bluetooth 5.4 and an Intel I225-V 2.5 Gigabit Ethernet controller, while audio uses a Realtek ALC4080 codec. The rear I/O includes Thunderbolt 4 over USB-C at 40 Gb/s.
Compared with the MSI PRO Z790-A MAX WiFi, the Tomahawk MAX adds two more SATA ports and a stronger 90 A power stage rating versus the PRO board’s 80 A stages. Compared with the ASUS TUF Gaming Z790-Plus WiFi, the Tomahawk MAX includes Wi-Fi 7 instead of Wi-Fi 6 and doubles the SATA port count from four to eight, though the ASUS board offers a comparable 16+1 DrMOS VRM design at a similar price point.
MSI PRO Z790-A MAX WiFi
CHECK PRICE
PROS
CONS
| Specification | MSI PRO Z790-A MAX WiFi |
|---|---|
| Chipset | Intel Z790 |
| Form Factor | ATX |
| VRM | 16+1+1 phases, 80 A power stages |
| Memory | 4x DDR5, up to 7,800 MT/s (OC) |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4 mode), 1x PCIe 3.0 x16 (x1 mode), 1x PCIe 3.0 x1 |
| Storage | 4x M.2 (PCIe 4.0), 6x SATA III |
| Networking | Wi-Fi 7, Bluetooth 5.4, 2.5G LAN |
| Audio | Realtek ALC4080 |
| Rear USB | USB 3.2 Gen 2×2 Type-C (20 Gb/s) |
| Approximate Price | $180–$200 |
The MSI PRO Z790-A MAX WiFi is an ATX motherboard built on the Intel Z790 chipset with a 16+1+1 phase Duet Rail Power System VRM rated at 80 A per power stage, powered by dual 8-pin EPS connectors. This VRM rating provides enough sustained current for the i5-14600K’s 181 W turbo power draw, and the extended VRM heatsink with 7W/mK thermal pads keeps power-stage temperatures controlled during multi-core loads.
Four DDR5 DIMM slots support Memory Boost overclocking to rated speeds of 7,800 MT/s and above. The expansion layout includes a PCIe 5.0 x16 slot, a PCIe 4.0 x16 slot at x4 electrical bandwidth, a PCIe 3.0 x16 physical slot running at x1, and an additional PCIe 3.0 x1 slot. Storage covers four M.2 slots at PCIe 4.0 speeds and six SATA III ports. Wi-Fi 7 with Bluetooth 5.4 and a 2.5G LAN controller handle networking, and the board includes USB 3.2 Gen 2×2 Type-C at 20 Gb/s.
Compared with the MSI MAG Z790 Tomahawk MAX WiFi, the PRO Z790-A MAX drops two SATA ports and 10 A of power-stage rating in exchange for a lower list price. Compared with the Gigabyte Z790 AORUS Elite AX, both boards target a similar budget tier, but the MSI PRO board includes Wi-Fi 7 while the Gigabyte board ships with Wi-Fi 6E.
Gigabyte Z790 AORUS Elite AX
CHECK PRICE
PROS
CONS
| Specification | Gigabyte Z790 AORUS Elite AX |
|---|---|
| Chipset | Intel Z790 |
| Form Factor | ATX |
| VRM | Twin 16+1+2 phases, 70 A power stages |
| Memory | 4x DDR5, up to 7,600+ MT/s (OC) |
| PCIe Slots | 1x PCIe 5.0 x16, 2x PCIe 4.0 x16 (x4 mode) |
| Storage | 4x M.2 (PCIe 4.0 x4), 6x SATA 6Gb/s |
| Networking | Wi-Fi 6E, Bluetooth 5, 2.5GbE LAN |
| Audio | Realtek HD audio codec |
| Rear USB | USB 3.2 Gen 2×2 Type-C (20 Gb/s) |
| Approximate Price | $190–$230 |
The Gigabyte Z790 AORUS Elite AX is an ATX motherboard on the Intel Z790 chipset with a twin 16+1+2 phase digital VRM using 70 A power stages arranged in an 8+8 parallel configuration. This VRM design supplies stable current for the i5-14600K’s 181 W turbo draw at stock settings and moderate all-core overclocks, though it carries a lower per-stage amperage rating than several other boards in this lineup.
Four DDR5 DIMM slots reach rated overclocked speeds beyond 7,600 MT/s with XMP 3.0 support. The primary PCIe 5.0 x16 slot is joined by two additional PCIe 4.0 x16 slots that run at x4 electrical bandwidth. Storage includes four PCIe 4.0 x4 M.2 slots and six SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support. Networking uses Wi-Fi 6E with Bluetooth 5 and a 2.5GbE LAN controller, and the rear I/O provides a USB 3.2 Gen 2×2 Type-C port alongside HDMI and DisplayPort outputs.
Compared with the MSI PRO Z790-A MAX WiFi at a similar price, the AORUS Elite AX uses a lower 70 A power-stage rating against MSI’s 80 A stages, but it matches the SATA port count at six. Compared with the ASUS TUF Gaming Z790-Plus WiFi, the AORUS Elite AX offers one additional PCIe 4.0 x16 slot but drops from Wi-Fi 6 to the newer Wi-Fi 6E standard.
ASUS TUF Gaming Z790-Plus WiFi
CHECK PRICE
PROS
CONS
| Specification | ASUS TUF Gaming Z790-Plus WiFi |
|---|---|
| Chipset | Intel Z790 |
| Form Factor | ATX |
| VRM | 16+1 DrMOS, 60 A power stages |
| Memory | 4x DDR5, up to 7,800+ MT/s (OC) |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4 mode), 1x PCIe 4.0 x4, 2x PCIe 3.0 x1 |
| Storage | 4x M.2 (PCIe 4.0), 4x SATA 6Gb/s |
| Networking | Wi-Fi 6 (AX201), 2.5GbE LAN (Intel I225-V) |
| Audio | Realtek S1220A with DTS |
| Rear USB | USB 3.2 Gen 2×2 Type-C, Thunderbolt 4 (USB4) header |
| Approximate Price | $187–$230 |
The ASUS TUF Gaming Z790-Plus WiFi is an ATX motherboard on the Intel Z790 chipset with a 16+1 DrMOS VRM using 60 A power stages for both the CPU and SoC rails, backed by Digi+ VRM digital power control and an enlarged VRM heatsink. This power-stage rating supports the i5-14600K’s 181 W turbo draw at stock operation and light-to-moderate overclocking, with ProCool power connectors that reduce connector-level power loss.
Four DDR5 DIMM slots reach rated overclocked speeds up to 7,800 MT/s and beyond. The expansion layout includes a PCIe 5.0 x16 slot in a reinforced SafeSlot, a PCIe 4.0 x16 slot at x4 bandwidth, a dedicated PCIe 4.0 x4 slot, and two PCIe 3.0 x1 slots. Storage covers four PCIe 4.0 M.2 slots, three with dedicated heatsinks, and four SATA 6Gb/s ports. Networking runs on Wi-Fi 6 (Intel AX201) with an Intel I225-V 2.5GbE controller, and the board includes a Thunderbolt 4 (USB4) header alongside a Realtek S1220A audio codec with DTS processing.
Compared with the Gigabyte Z790 AORUS Elite AX, the TUF Gaming Z790-Plus WiFi offers four SATA ports against Gigabyte’s six, but adds a Thunderbolt 4 header that the Gigabyte board omits. Compared with the MSI MAG Z790 Tomahawk MAX WiFi, the ASUS board uses an older Wi-Fi 6 module instead of Wi-Fi 7 and provides half the SATA port count.
Gigabyte Z790 AORUS Pro X WiFi 7
CHECK PRICE
PROS
CONS
| Specification | Gigabyte Z790 AORUS Pro X WiFi 7 |
|---|---|
| Chipset | Intel Z790 |
| Form Factor | ATX |
| VRM | Digital twin 18+1+2 phases |
| Memory | 4x DDR5, up to 8,266 MHz (OC) |
| PCIe Slots | 1x PCIe 5.0 x16 |
| Storage | 5x M.2 (1x PCIe 5.0 x4, 4x PCIe 4.0 x4), 4x SATA 6Gb/s |
| Networking | Wi-Fi 7 (Intel BE200), Bluetooth 5.4, 5GbE LAN |
| Audio | Realtek ALC1220 |
| Rear USB | Front and rear USB-C (20 Gb/s) |
| Approximate Price | $300–$490 |
The Gigabyte Z790 AORUS Pro X WiFi 7 is an ATX motherboard on the Intel Z790 chipset with a digital twin 18+1+2 phase VRM, the highest phase count in this lineup, built to support sustained turbo boost and overclocking on higher-power Intel processors. This VRM configuration provides substantial headroom above the i5-14600K’s 181 W turbo power draw, keeping voltage stable during extended all-core workloads.
Four DDR5 DIMM slots support rated overclocked speeds up to 8,266 MHz, the highest memory speed rating among the six boards. The primary PCIe 5.0 x16 slot uses Gigabyte’s reinforced PCIe UD Slot X design. Storage totals five M.2 slots, including one PCIe 5.0 x4 slot from the CPU and four PCIe 4.0 x4 slots split between the CPU and chipset, one of which also supports SATA mode, alongside four SATA 6Gb/s ports. Networking includes Wi-Fi 7 (Intel BE200) with Bluetooth 5.4 and a 5GbE LAN controller, and the board carries an ALC1220 audio codec with audiophile-grade capacitors.
Compared with the MSI MPG Z790 Carbon MAX WiFi II, the AORUS Pro X WiFi 7 provides one more M.2 slot but two fewer SATA ports. Compared with the Gigabyte Z790 AORUS Elite AX, the Pro X WiFi 7 raises the VRM phase count from 16 to 18, upgrades wireless networking from Wi-Fi 6E to Wi-Fi 7, and doubles the wired LAN speed from 2.5GbE to 5GbE.
MSI MPG Z790 Carbon MAX WiFi II
CHECK PRICE
PROS
CONS
| Specification | MSI MPG Z790 Carbon MAX WiFi II |
|---|---|
| Chipset | Intel Z790 |
| Form Factor | ATX |
| VRM | Direct 19+1+1 phases, 105 A power stages |
| Memory | 4x DDR5, up to 7,800 MT/s (OC) |
| PCIe Slots | 1x PCIe 5.0 x16, 1x PCIe 4.0 x16, 1x PCIe 3.0 x1 |
| Storage | 5x M.2 (1x PCIe 5.0 x4, 4x PCIe 4.0 x4), 6x SATA 6Gb/s |
| Networking | Wi-Fi 7, 2.5GbE LAN |
| Audio | Onboard HD audio with isolated PCB layers |
| Rear USB | USB4, USB 3.2 Gen 2×2 |
| Approximate Price | $400–$460 |
The MSI MPG Z790 Carbon MAX WiFi II is an ATX motherboard on the Intel Z790 chipset with a direct 19+1+1 phase VRM, the second-highest phase count in this lineup, using 105A Smart Power Stages fed by dual 8-pin EPS connectors. This VRM design delivers substantial current headroom above the i5-14600K’s 181 W turbo draw and supports extended overclocking on higher-power Intel Core processors.
Four DDR5 DIMM slots reach rated overclocked speeds up to 7,800 MT/s. Expansion includes two PCIe x16 slots, one running at PCIe 5.0 and one at PCIe 4.0, plus a PCIe x1 slot. Storage totals five M.2 slots, with one PCIe 5.0 x4 slot from the CPU and the remaining four at PCIe 4.0 x4 (one supporting SATA mode), alongside six SATA 6Gb/s ports. Networking runs on Wi-Fi 7 with a 2.5GbE LAN controller, and the rear I/O includes a USB4 port alongside USB 3.2 Gen 2×2 connectivity.
Compared with the Gigabyte Z790 AORUS Pro X WiFi 7, the Carbon MAX WiFi II adds two extra SATA ports and a USB4 port but rates its VRM at 105 A per stage against the Gigabyte board’s unlisted per-stage rating at 18 phases. Compared with the MSI MAG Z790 Tomahawk MAX WiFi, the Carbon MAX WiFi II raises the VRM phase count from 16 to 19 and adds a fifth M.2 slot, positioning it as the higher-tier option within the MSI lineup covered in this article.
How to Choose a motherboard for i5 14600K
The right motherboard for the i5-14600K matches the CPU’s 181 W turbo power draw to a VRM with sufficient phase count and power-stage amperage, pairs that VRM with the memory speed, storage, and connectivity a specific build requires, and fits the available budget.
VRM capacity determines how well a board sustains the i5-14600K’s turbo power under prolonged multi-core loads and overclocking. A VRM rated at 16 phases or more with power stages of 70 A or higher, such as the boards reviewed above, supplies stable voltage at stock settings and moderate overclocks. Builds that plan aggressive all-core overclocking benefit from higher-rated VRMs, such as the 18+1+2 phase design on the Gigabyte Z790 AORUS Pro X WiFi 7 or the 19+1+1 phase, 105 A design on the MSI MPG Z790 Carbon MAX WiFi II.
Memory speed requirements depend on the workload. Gaming and general productivity run well on DDR5 kits between 6,000 MT/s and 7,200 MT/s, a range every board in this lineup supports. Builds seeking the highest rated memory overclocks benefit from the Gigabyte Z790 AORUS Pro X WiFi 7, which supports speeds up to 8,266 MHz.
Storage needs vary by build type. A system with two or three NVMe drives and a couple of SATA drives runs well on any board in this lineup, since all six include at least four M.2 slots. Builds planning five or more storage devices benefit from the Gigabyte Z790 AORUS Pro X WiFi 7 or the MSI MPG Z790 Carbon MAX WiFi II, which each provide five M.2 slots.
Connectivity requirements narrow the choice further. Builds that need Thunderbolt or USB4 for external storage or capture devices should prioritize the ASUS TUF Gaming Z790-Plus WiFi, the MSI MAG Z790 Tomahawk MAX WiFi, or the MSI MPG Z790 Carbon MAX WiFi II. Builds prioritizing wired network speed benefit from the 5GbE LAN controller on the Gigabyte Z790 AORUS Pro X WiFi 7, while builds on a fixed budget benefit from the lower-cost MSI PRO Z790-A MAX WiFi or Gigabyte Z790 AORUS Elite AX, both of which still meet the i5-14600K’s power requirements at stock settings.
